V6 VMAX SHO® 225 HP
V6 VMAX SHO® 225 HP
Outboard
Overview
Originally engineered to exceed expectations, the V6 V MAX SHO® 225 has done it again. It’s now sporting 40 percent more charging power and a striking new cowling design. On top of its instant hole shot and exhilarating top speed, it has all the tools in the tackle box to compete.
- New alternator output: up to 70 gross amps
- Super High Output 60-degree 4.2-liter V6 Design
- Minimum 89 Octane
- 20” shaft only
| Engine Type | V6 |
| Displacement | 4.2L |
| Bore x Stroke | 96 x 96mm (3.78 x 3.78 in) |
| Prop Shaft Horsepower | 225hp at 5500 rpm |
| Full Throttle RPM Range | 5000 ~ 6000 rpm |
| Alternator Output at W.O.T. | 70 Amp |
| Compression Ratio | 10.3:1 |
| Fuel Induction System | EFI |
| Weight † | 240 kg (529 lbs) |
| Recommended Fuel | Octane 89 |
| Recommended Engine Oil | Yamalube® 4M (See owner's manual) |
| Recommended Fuel Filtration | Yamaha 10-Micron Fuel/Water Separating Filter (external) |
| C.A.R.B. Rating | 3-Star |
| Exhaust | Through Propeller |
| Intake | 24 |
| Ignition | TCI Microcomputer |
| Spark Plug | LFR6A-11 |
| Alternator Output | 50 Amp |
| Starting System | Electric |
| Lubrication | Wet Sump |
| Engine Oil Capacity | 6.7L/6.4L |
| Recommended Cooling | Thermostatic Control |
| Ethanol Blend Limit | 10% Maximum |
| Gear Ratio | 1.75:1 |
| Gear Shift | Forward, Neutral, Reverse |
| Shaft Length | 20" - 25" |
| Degree of Tilt | 66° |
| Degree of Trim | -4° through +16° |
| Dry Weight | 20" shaft / 240 kg (529 lbs), 25" shaft / 257 kg (567 lbs) |
| Mounting Centers | N/A |
| Steering Angle (maximum) | 35° from center, either direction |
| Warranty | Limited 3-year Pleasure, 3-year Government, 1-Year Commercial |
